| 液压过载保护装置 | Hydraulic overload protection device(king-air |
| 干式气动摩擦离合器、制动器 | Air actuated dry runing clutch and brake |
| 电动润滑油泵 | Electric lubricating oil pump |
| PLC／触摸屏 | Programmable Logic Controller/touch screen(Delta)(WEINVIEW |
| 接触器、电机过载保护器 | Contactor/thermal overload relay(Shneider Electric |
| 电源相序保护器 | Voltage phase sequence protector |
| 双色状态监视灯 | Signal Light |
| 绝对值编码器／接近传感器 | Absolute rotary encoder/PROXIMITY SENSORS(OMRON) |
| 铝合金悬臂操控箱 | Aluminium alloy suooort arm control systems |
| 伺服多工位锻压搬运机械手 | Servo multi station forging and conveying manipulator |
| 锻压模架／下顶料装置 | Forging die/Under liftout attachment |
| 中频加热炉/自动上料一体机 | Medium frequency Induction heating/AUTO loading bar stock |
| 水冷却系统 | Water cooling equipment |
| 安全保护光幕 | Safety Light Curtains |
| 松下微型激光位移传感器 | CMOS type Micro laser Distance Sensor |
◆ Fast speed: completely synchronized with the punching machine, that is, the punching machine is mechanically manual, the punching machine stops the robot, stops the pause time, and the production efficiency is high. The punching machine of 60 punch/minute can produce 45 products/minute;
◆ Easy to make: Control by the button, adjust the robot movement on the touch screen, no need to remove the claw when changing the mold;
◆ There are many functions: there is a single punching action, that is, the punching machine produces one finished product twice per movement, which is suitable for producing larger products. It is also possible to move the robot first, and after the punching, it can produce a product with a height of 80 left stone. Alarm function, partial failure Can alarm shutdown.
